2000W PIR & Photocell External Light Sensor Black
£16.02 (Inc. VAT at 20%)
£13.35 (Exc. VAT)The SLB2301 is a powerful PIR sensor suitable for new and existing installations, it features a sensitive PIR sensor that detects motion across 180° up to 12 metres when mounted at 2.5 metres. Light levels can be adjusted, from 2 to 1000 LUX, and set the time duration from 2 seconds to 15 minutes to suit your needs. The pan and tilt function allows you to customise the detection zone, while the manual override and adjustable sensitivity provide full control over operation. With an impressive IP65 rating, this controller is fully protected against dust and low-pressure water jets from any direction, making it ideal for indoor and outdoor use.
Additional features include Dusk Level Adjustment: LUX Learn mode, Day & Night or Night time only operation. Conforms to BS EN 61347 and comes with a 3 year guarantee.
- Total PIR switching: 2000W halogen, 400W LED
- Pan and tilt feature
- Light ON times adjustable from 2 seconds to 15 minutes
- LUX (light level) adjustment – Day to Night (2 to 1000)
- Manual ON/OFF switching override
- Protection rating IP65
- Simple push fit terminals for easy fitting
2000W PIR & Photocell External Light Sensor Black is backordered and will ship as soon as it is back in stock.
2000W PIR & Photocell External Light Sensor Black
£16.02 (Inc. VAT at 20%)
£13.35 (Exc. VAT)Extended Product Description for SLB2301 2000W PIR & Photocell Light Controller
The SLB2301 2kW PIR & Photocell Light Controller is a robust and versatile solution for managing lighting systems in residential, commercial, or outdoor spaces. With its advanced passive infrared (PIR) technology and impressive detection range, this controller is perfectly suited for both new and existing installations requiring reliable motion-activated lighting.
Advanced PIR Detection and Coverage
The SLB2301 features a 12m detection range and 180 degree field of coverage, ensuring comprehensive monitoring for a wide array of lighting situations.
Optimised Light Switching and Performance
Engineered for efficient operation, the SLB2301 can switch up to 2000W of halogen light, 400W of fluorescent/low energy lights, and 400W of LED lighting, making it highly capable across diverse lighting types. The controller includes a pan and tilt function for precise aiming, ensuring the PIR sensor is directed exactly where you need it most.
Adjustable Timings and LUX Levels
The SLB2301 offers customisable light ON times, which can be set from as short as 2 seconds to as long as 15 minutes, depending on your preference or activity. Additionally, the LUX adjustment feature enables you to fine-tune the controller's light level sensitivity between daylight (1000 LUX) and near darkness (2 LUX), ensuring lighting activates only when needed and conserving energy.
Convenience and Durability
For added functionality, the SLB2301 includes a manual override option, enabling you to switch the light ON or OFF manually when necessary. Its IP65 protection rating ensures superior resistance against dust and low-pressure water streams, making it ideal for outdoor use in even challenging weather conditions.
Quick Installation
Featuring push-fit terminals, the SLB2301 is designed for quick, hassle-free installation, even for DIY users.
Peace of Mind Guarantee
The SLB2301 PIR & Photocell 2kW Standalone also comes with a 3 year guarantee, assuring you of its quality, reliability, and long-term performance.
Key Features at a Glance
PIR Detection Range:12 metres with 180 degree coverage.
Light Switching Capacities:
2000W halogen.
400W fluorescent.
400W LED.
Customisable Light ON Times: Adjustable from 2 seconds to 15 minutes.
LUX Sensitivity Setting: Adjustable from 2 LUX (dark) to 1000 LUX (daylight).
Pan and Tilt Adjustment: For accurate sensor positioning.
Manual Override Option: Provides added flexibility.
Protection Rating: A high IP65 for dust and water resistance.
Ease of Installation: Push-fit terminals for quick setup.
Warranty: 3 year guarantee for added assurance.
The SLB2301 2200W PIR & Photocell Light Controller is the ideal choice for anyone seeking efficient and customisable lighting control, whether for indoor or outdoor applications. Delivering exceptional performance, convenience, and durability, it is a smart addition to any lighting system.
Specs Sheet - SLB2301 2kW PIR & Photcell Standalone Light Controller
Product Name: PIR & Photocell 2kW Standalone Black
Part Number: SLB2301
Brand: Timeguard
Key Specifications:
Detection Range: 12 metres
Field of Coverage: 180 degrees
PIR Switching Capacities:
2000W halogen
400W fluorescent
400W LED
Features:
Customisable Light ON Times: Adjustable from 2 seconds to 15 minutes
LUX Sensitivity Adjustment: 2 LUX (dark) to 1000 LUX (daylight)
Pan and Tilt Adjustment: For precise sensor alignment
Manual Override Function: Allows lights to be switched ON or OFF manually
Design and Installation Details:
Protection Rating: IP65 (dust and water-resistant)
Installation Method: Push-fit terminals
Guarantee: 3 year warranty included
With its robust design, flexible settings, and high compatibility across lighting types, the SLB2301 PIR 7 Photocell Light Controller is an ideal choice for efficient and effective lighting control in any space.
Frequently Asked Questions (FAQs) - SLB2301 2kW PIR & Photocell Standalone Light Controller
1. What is the detection range and coverage of the SLB2301?
The SLB2301 has a detection range of up to 12 metres and offers 180 degree coverage, providing reliable motion detection for various lighting applications.
2. Can I use this controller with different types of lights?
Yes, the SLB2301 is compatible with multiple lighting types, including halogen, CFL, Fluorescent and LED lights, making it highly versatile.
3. How do I install the SLB2301 PIR Light Controller?
The controller is designed for easy installation with simple push-fit terminal block connectors.
4. Does the SLB2301 include any safety features?
Yes, the controller is rated IP65 for dust and water resistance, ensuring durability and reliable performance even in outdoor environments.
5. Is there a manual override option for the light controller?
Yes, the SLB2301 features a manual ON/OFF override, allowing you to manually control the lights when needed, in addition to its motion-activated operation.
