TecMotors 1.1kW 2 Pole Electric Motor, Three Phase, B3 Foot Mounted, Frame Size 80, IE3 Efficiency

The 1.123TECAB3-IE3 is a 1.1kW, 2 pole, three phase electric motor. Built from durable aluminium with a multi-mount IEC frame, the motor offers excellent flexibility when it comes to installation, thanks to its removable foot mounted design. Its continuous duty (S1) rating ensures it can run reliably over long periods without interruption, while the high quality NSK bearings guarantee smooth operation and extended service life. Rated to IP55, it is safeguarded against dust and water ingress, making it suitable for challenging working environments. Thermal protection is provided by PTC thermistors rated at 130°C, helping to prevent overheating and extend motor life. With Class F insulation and IC411 cooling, it is built for dependable and safe operation.

Can be used with DOL (direct online), inverters and soft starts. Manufactured in compliance with IEC 60034-5 standards, this compact and versatile electric motor designed to deliver reliable performance in a wide range of industrial applications.

• 1.1kW output power
• Three phase
• B3 foot mounting
• IE3 efficiency
• Lightweight aluminium construction
• Frame size 80
• Insulation class F
• S1 continuous duty
• TEFC - totally enclosed motor, fan cooled
• Rated IP55
• Shaft diameter 19mm
