TecMotors 110kW 6 Pole T4C Cast Iron Electric Motor, Three Phase, B3 Foot Mounted, Frame Size 315L1-6, IE4 Efficiency

Extended Product Description for TecMotors 110kW 6 Pole T4C Cast Iron Electric Motor

The TecMotors 110kW 6 Pole T4C Cast Iron Electric Motor is an exemplary solution for industries seeking reliable, high-performance, and energy efficient equipment. Designed to excel in demanding environments, this motor combines cutting edge efficiency with robust construction and versatility, guaranteeing lasting value for industrial applications.

Top-Tier Energy Efficiency

With its IE4 Super Premium Efficiency rating, the motor stands among the most energy efficient electric motors available in the market. This efficiency rating ensures significant reductions in energy consumption and operational costs while delivering superior environmental benefits. It is optimized for use with inverters, enabling smooth and energy-efficient power delivery across various industrial systems.

Durable and Robust Design

Crafted with heavy duty cast iron, the motor exhibits exceptional durability and resilience against industrial wear and tear. Its Totally Enclosed Fan Cooled (TEFC) design acts as a comprehensive barrier against dust, dirt, and moisture, ensuring the motor performs consistently even in challenging environments. Whether positioned in heavy industrial facilities or tough outdoor applications, the motor delivers reliable and uninterrupted performance.

Enhanced Protection for Reliable Operation

The IP55 rating reflects the motor’s strong defense against solid contaminants and low-pressure water jets, making it suitable for demanding industrial and outdoor settings. The inclusion of PTC thermistors adds a layer of thermal protection, actively monitoring internal temperatures to prevent overheating and ensure safe, seamless operation.

High Quality Engineering and Compliance

Equipped with NSK bearings, this motor not only supports smooth, low-maintenance operation but also extends the lifespan of the unit. Built to comply with IEC 60034 standards, it meets rigorous global benchmarks for safety, reliability, and quality, offering complete peace of mind to operators.

Technical Excellence and Adaptability

Delivering an impressive 110kW output power at 1000 RPM, this motor is a powerhouse fit for high demand industrial applications. The B3 foot-mounted design and multimount frame provide excellent flexibility during installation, allowing seamless integration into various setups. Other specifications, such as a Frame Size of 315L1-6, Insulation Class F, and an 80mm shaft diameter, further underscore its suitability for heavy industrial use.

Broad Applications Across Industries

The motor’s rugged build and efficiency make it suitable for diverse applications, including but not limited to:
Pumps and Compressors: Ensures continuous and efficient fluid or air movement.
Manufacturing Equipment: Powers production lines with consistent, dependable energy.
HVAC Systems: Facilitates optimal airflow and temperature control in industrial facilities.
Material Handling Machinery: Provides the stability and precision necessary for lifting and transporting heavy loads.
Outdoor Operations: Withstands tough environmental factors while preserving efficiency.

Key Features at a Glance

Power Output: 110kW

Rotational Speed: 1000 RPM

Efficiency Class: IE4 Super Premium Efficiency for maximum energy savings

Construction Material: Tough cast iron for superior strength and longevity

Design: TEFC design for protection against contaminants

IP Rating: IP55 for resistance to dust and moisture

Thermal Protection: Built-in PTC thermistors for heat management

Mounting Style: B3 foot-mounted for flexible installation options

Shaft Diameter: 80mm

Compliance: Meets IEC 60034 safety and quality standards

Why Choose the TecMotors 110kW 6 Pole Motor?

The TecMotors 110kW 6 Pole T4C Cast Iron Electric Motor is a blend of efficiency, durability, and versatility. Its cutting edge energy saving capabilities align with the goals of industries striving to reduce environmental footprints and operational costs. Meanwhile, the rugged design, superior components, and comprehensive thermal and environmental protections ensure reliable performance in any setting. Whether for manufacturing, material handling, or outdoor systems, this motor is the go-to choice for businesses seeking a long-lasting, high-performing power unit. Choose the TecMotors 110kW 6 Pole Motor for seamless operation, reduced costs, and unmatched durability in your industrial applications.

Specs Sheet - TecMotors 110kW 6 Pole T4C Cast Iron Electric Motor

Product Name: TecMotors 110kW 6 Pole T4C Cast Iron Electric Motor

Part Number: 110.063TECCB3-IE4

Specifications Overview:

Efficiency Class: IE4 Super Premium Efficiency for superior energy savings and reduced operational costs.

Construction Material: Heavy duty cast iron for durable and long-lasting performance in demanding environments.

Design: Totally Enclosed, Fan Cooled (TEFC) to protect internal components from harmful contaminants like dust, dirt, and moisture.

IP Rating: IP55, providing reliable protection against dust ingress and low-pressure water jets.

Thermal Protection: Integrated PTC thermistors to monitor and protect against overheating.

Bearings: Fitted with high quality NSK bearings for smooth operation and low maintenance.

Compliance: Adheres to IEC 60034 standards for global safety and quality assurance.

Performance Details:

Power Output: 110kW

Speed: 1000 RPM

Frequency: 50/60Hz adaptable for varying industrial systems.

Efficiency: Optimized for inverter use, ensuring stable and energy-efficient operation.

Insulation Class: Class F for reliability under thermal stress in high-demand conditions.

Mechanical Specifications:

Frame Size: 315L1-6

Mounting Style: B3 Foot Mounted for secure and hassle-free set up.

Phase: Three phase, ideal for heavy industrial and large-scale applications.

Shaft Diameter: 80mm

Installation & Adaptability:

Multimount Frame: Designed to enable seamless integration across various industrial setups.

Environment Suitability: Build and protection make it the ideal choice for industrial facilities, outdoor installations, and complex manufacturing plants.

Key Features & Benefits:

Energy Efficiency: A premium IE4 rating that reduces energy consumption for cost effective and eco-conscious operations.

Heavy Duty Construction: Cast iron build ensures robustness and resistance to wear and tear.

Contaminant Protection: TEFC design combined with IP55 rating enhances durability in challenging environments.

Thermal Regulation: PTC thermistors prevent overheating for consistent, safe usage.

Premium Bearings: NSK bearings ensure reliability and long-term performance with minimal maintenance required.

Applications:

Industrial Processes: Powers complex manufacturing systems with consistent performance.

Outdoor Machinery: Resilient against environmental challenges like dust and moisture.

HVAC Systems: Supports efficient control over air circulation and cooling processes.

Pumps and Compressors: Enables steady operation for liquid or gas movement in industrial setups.

Material Handling: Ideal for equipment that handles heavy lifting and transportation tasks.

Why Choose This Motor?

The TecMotors 110kW 6 Pole T4C Cast Iron Electric Motor provides a perfect combination of efficiency, durability, and versatility. Its advanced engineering, combined with robust protection mechanisms and energy saving capabilities, makes it a reliable solution for even the toughest industrial applications. Select this motor for unmatched performance, operational reliability, and long term energy savings.

Frequently Asked Questions (FAQs) - TecMotors 110kW 6 Pole T4C Cast Iron Electric Motor

1. Why is the TecMotors 110kW 6 Pole Motor considered energy efficient?

This motor is rated IE4 Super Premium Efficiency, one of the highest efficiency levels for electric motors. It significantly reduces energy consumption and operational costs while being optimized for use with variable speed inverters to maximize power efficiency.

2. How is this motor installed?

The motor features a B3 foot-mounted design along with a multimount frame for flexible and hassle-free installation. This allows it to easily fit into new or existing industrial equipment with minimal modifications.

3. What maintenance does this motor require?

Routine maintenance involves cleaning the motor’s exterior to prevent debris accumulation, checking and lubricating the NSK bearings, and monitoring the PTC thermistors to ensure the motor does not overheat. Regular inspections will help maintain its optimal performance and extend its lifespan.

4. Is this motor suitable for harsh environments?

Yes, it is designed for demanding industrial and outdoor applications. The heavy duty cast iron construction, TEFC design, and IP55 rating protect the motor from dust, dirt, and moisture, making it durable and reliable under challenging conditions.

5. What should I do if the motor encounters performance issues?

Start by ensuring all electrical connections are secure and free of damage. Check for airflow obstructions that might cause overheating. If the issue persists or the PTC thermistors signal excessive heat, refer to the product manual or contact TecMotors’ technical support for assistance.
