TecMotors 11kW 4 Pole 3 Phase Cast Iron Electric Motor IE3 B3 Foot Mounted, Frame Size 160
£780.24 (Inc. VAT at 20%)
£650.20 (Exc. VAT)The 11.043TECCB3-IE3 is a 11kW, 4 pole, three phase electric motor with an IE3 efficiency rating and B3 foot mounting, with removable feet. Its frame and terminal box are made from cast iron, with a sheet steel fan cover and cast iron flanges and shields.
The motor is rated IP55, providing protection against dust and water jets. It has Class F insulation and IC411 cooling, with PTC (positive temperature coefficient) thermistors as standard. Fitted with NSK bearings.
This T3C motor conforms to IEC 60034 standards and has an S1 continuous duty rating.
This heavy duty, TEC cast iron motor is suitable for a range of industrial applications, including pumps, air compressors, fans, conveyors, material handling equipment and power transmission systems. It can also be used in wastewater treatment, agriculture, mining and other industrial environments.
Interested in saving money on energy costs? Speak to us about TECDrive inverters for motor speed control and potential energy savings. TEC also supplies gearboxes and geared motors for applications requiring torque control and power transmission, giving you the option to source the motor, inverter and gearbox together.
- 11kW output power
- 4 pole
- Three phase
- 1450 RPM
- B3 foot mounting
- Removable feet
- IE3 efficiency rating
- Heavy duty, cast iron construction
- Frame size 160M-4
- 50/60Hz
- Insulation class F
- S1 continuous duty
- IP55 protection
- Forward and reverse rotation
- Shaft diameter 42mm
TecMotors 11kW 4 Pole 3 Phase Cast Iron Electric Motor IE3 B3 Foot Mounted, Frame Size 160 is backordered and will ship as soon as it is back in stock.
TecMotors 11kW 4 Pole 3 Phase Cast Iron Electric Motor IE3 B3 Foot ...
£780.24 (Inc. VAT at 20%)
£650.20 (Exc. VAT)Extended Product Description for TEC 11kW 4 Pole Cast Iron Electric Motor - 11.043TECCB3-IE3
Overview:
Experience unmatched performance and efficiency with the TEC IE3 11kW 4 Pole Cast Iron Motor, designed to meet the rigorous demands of modern industrial applications. Engineered for versatility and high performance, this motor features a robust cast iron construction and a B3 mounting configuration, ensuring ease of installation and long term durability. Rated with IE3 efficiency, it offers exceptional energy savings and is ideal for inverter use, making it a valuable addition to any industrial setup.
Key Features:
High Output Power:Delivering a strong 11kW output, this motor is capable of handling heavy duty tasks with ease, providing consistent and reliable performance across various applications.
Versatile B3 Mounting:Featuring B3 mounting, the motor provides stability with a foot mounting option, allowing easy integration into diverse systems and configurations.
Robust Cast Iron Construction:Constructed from high quality cast iron, the motor is built to withstand harsh industrial environments, offering superior resistance to wear, corrosion, and mechanical stress.
Frame Size 160:Its 160 frame size ensures compatibility with industry-standard equipment, facilitating seamless installation in a wide range of setups.
Three Phase Operation:Designed for three phase power supply, this motor is suitable for industrial and commercial applications, offering enhanced performance and efficiency.
Insulation Class F:Equipped with class F insulation, the motor can safely operate at higher temperatures without compromising performance or safety.
IE3 Efficiency: Rated with IE3 efficiency, the motor meets premium efficiency standards, ensuring reduced energy consumption and operational costs while reducing environmental impact.
Detailed Specifications:
Output Power:11kW
Number of Poles:4
Mounting Type:B3 (foot)
Construction Material:Cast Iron
Frame Size:160
Model Number:11.043TECCB3-IE3
Power Supply:Three phase
Insulation Class:F
Efficiency Class:IE3 (premium efficiency)
Thermal Protection:PTC thermistors fitted as standard
Duty Cycle: S1 (continuous duty)
Performance and Efficiency:
Superior Energy Efficiency:The IE3 efficiency rating ensures minimal energy loss, reducing operational costs and contributing to environmental sustainability by lowering carbon emissions.
Reliable Operation:The motor's robust design and high-grade materials ensure smooth and consistent performance, making it ideal for demanding industrial tasks.
Applications:
The TEC IE3 11kW 4 Pole Cast Iron Motor is versatile and suitable for a range of heavy duty applications, including but not limited to:
Pumps:Ideal for driving large fluid pumping systems, delivering powerful and efficient performance.
Fans:Suitable for industrial ventilation and cooling systems, ensuring reliable airflow management.
Compressors:Effective in heavy duty air compression systems requiring steady and robust performance.
Conveyor Systems: Perfect for powering large conveyor belts and automated material handling systems in industrial environments.
General Machinery:Suitable for various types of industrial machinery requiring dependable and high performance power solutions.
Compliance and Standards:
Standards Compliance:Manufactured in compliance with IEC 60034 standards, ensuring adherence to international quality and safety regulations.
Efficiency Standards:Meets IE3 efficiency standards, guaranteeing premium energy efficiency and performance.
Summary:
The TEC IE3 11kW 4 Pole Cast Iron Motor is a highly efficient and reliable solution for heavy duty industrial applications. Its robust cast iron construction, versatile B3 mounting, and premium IE3 efficiency rating make it ideal for demanding environments. With superior energy efficiency, consistent performance, and compliance with international standards, this motor delivers exceptional value and reliability, making it an essential component for any industrial setup requiring powerful and efficient operation.
Specs Sheet for TEC 11kW 4 Pole Cast Iron Motor - 11.043TECCB3-IE3
Product Overview:
The TEC IE3 11kW 4 Pole Cast Iron Motor is engineered for high performance and efficiency in demanding industrial applications. With a robust cast iron construction, versatile B3 mounting configuration, and premium IE3 efficiency rating, this motor is designed to deliver reliable power while reducing energy consumption.
Key Specifications:
Product Name:TEC 11kW 4 Pole Cast Iron Motor
Model Number:11.043TECCB3-IE3
Output Power:11kW
Number of Poles:4
Mounting Type:B3 (foot)
Construction Material:Cast Iron
Frame Size:160
Power Supply:Three phase
Insulation Class: F
Efficiency Class: IE3 (premium efficiency)
Protection Rating:IP55
Thermal Protection:PTC thermistors fitted as standard
Duty Cycle: S1 (continuous duty)
Electrical Specifications:
Rated Voltage: 400V
Frequency: 50Hz
Efficiency Class:IE3, indicating premium energy efficiency
Mechanical Specifications:
Frame Material:High quality cast iron, providing exceptional durability and resistance to harsh environments
Shaft Material:High grade steel for robust performance and longevity
Bearings:High performance NSK bearings designed to reduce friction and enhance motor life
Mounting Configuration: B3, foot mounting
Removable Feet: Allows flexibility for various installation requirements
Performance Specifications:
Efficiency: Optimised for high energy efficiency, contributing to reduced operational costs
Thermal Protection:PTC thermistors for enhanced thermal protection, preventing overheating
Continuous Duty:Rated for S1 continuous duty, ensuring reliable performance over extended periods
Special Features:
High Output Power:Delivers a strong 11kW output, capable of handling heavy duty tasks with ease
Durable Construction:Cast iron body ensures long lasting durability and resistance to wear and tear in industrial environments
IP55 Protection: Totally enclosed and protected against dust and water ingress from any direction, suitable for challenging environments
Premium Efficiency:IE3 efficiency rating ensures minimal energy loss, reducing operational costs and environmental impact
Applications:
Pumps: Ideal for driving large fluid pumping systems, delivering powerful and efficient performance
Fans: Suitable for industrial ventilation and cooling systems, ensuring reliable airflow management
Compressors:Effective in heavy duty air compression systems requiring steady and robust performance
Conveyor Systems: Perfect for powering large conveyor belts and automated material handling systems
General Machinery:Suitable for various types of industrial machinery requiring dependable and high performance power solutions
Compliance and Standards:
Standards Compliance:Manufactured in compliance with IEC 60034 standards, ensuring adherence to international quality and safety regulations
Efficiency Standards:Meets IE3 efficiency standards, guaranteeing premium energy efficiency and performance
Included Components:
Motor Unit:11kW 4 pole three phase cast iron motor
Mounting Hardware:Standard accessories for B3 foot mounting
Summary:
The TEC IE3 11kW 4 Pole Cast Iron Motor is a highly efficient and reliable solution for heavy duty industrial applications. Its robust cast iron construction, versatile B3 mounting, and premium IE3 efficiency rating make it ideal for demanding environments. With superior energy efficiency, consistent performance, and compliance with international standards, this motor delivers exceptional value and reliability, making it an essential component for any industrial setup requiring powerful and efficient operation.
Frequently Asked Questions for TEC 11kW 4 Pole Cast Iron Motor - 11.043TECCB3-IE3
1. What applications is the TEC 11kW 4 Pole Cast Iron Motor suitable for?
The TEC 11kW 4 Pole Cast Iron Motor is ideal for heavy duty industrial applications such as driving large fluid pumping systems, industrial ventilation and cooling fans, air compressors, conveyor belts, and various machinery that require reliable and efficient power solutions.
2. What does the IE3 efficiency rating mean for this motor?
The IE3 efficiency rating denotes premium energy efficiency, which translates to lower energy consumption, reduced operational costs, and a smaller environmental footprint. This makes the motor an excellent choice for businesses looking to improve their energy efficiency and sustainability.
3. How does the B3 mounting configuration benefit installation?
The B3 mounting configuration offers versatile installation options by providing both flange and foot mounting capabilities. This allows for easy integration into a wide range of setups, making it highly adaptable to different industrial applications.
4. What advantages does the cast iron construction provide?
The cast iron construction ensures exceptional durability and resistance to wear, corrosion, and mechanical stress. This robust build makes the motor suitable for harsh industrial environments, ensuring long term reliability and minimal maintenance requirements.
5. Is the TEC 11kW 4 Pole Cast Iron Motor compliant with international standards?
Yes, this motor is manufactured in compliance with IEC 60034 standards, ensuring it meets international quality and safety regulations. This guarantees reliable and safe operation across diverse industrial environments.
