TecMotors 200kW 4 Pole T4C 3 Phase Cast Iron Electric Motor IE4 B3 Foot Mounted, Frame Size 315L2-4
£8,616.34 (Inc. VAT at 20%)
£7,180.28 (Exc. VAT)The TEC 200.043TECCB3-IE4 is a 200kW, 4 pole, three phase, IE4 premium efficiency electric motor with B3 foot mounting. Its frame and terminal box are made from cast iron, with a sheet steel fan cover and cast iron flanges and shields.
The motor is rated IP55, providing protection against dust and water jets. It has Class F insulation and IC411 cooling, with PTC (positive temperature coefficient) thermistors. Fitted with NSK bearings.
This T4C motor conforms to IEC 60034 standards and has an S1 continuous duty rating. The motor's IE4 rating means it's in a "Super Premium Efficiency" class for electric motors, one of the highest efficiency levels available.
This heavy duty, TEC cast iron motor is suitable for a range of industrial applications, including pumps, air compressors, fans, conveyors, material handling equipment and power transmission systems. It can also be used in wastewater treatment, agriculture, mining and other industrial environments.
TEC also supplies gearboxes and geared motors for applications requiring torque control and power transmission. These can be used alongside electric motors to meet different drive and mechanical transmission requirements.
- 200kW output power
- 4 pole
- Three phase
- 1485 RPM
- B3 foot mounting
- IE4 Super Premium Efficiency rating
- Heavy duty, cast iron construction
- Frame size 315L2-4
- 50/60Hz
- Insulation class F
- S1 continuous duty
- IP55 protection
- Shaft diameter 80mm
TecMotors 200kW 4 Pole T4C 3 Phase Cast Iron Electric Motor IE4 B3 Foot Mounted, Frame Size 315L2-4 is backordered and will ship as soon as it is back in stock.
TecMotors 200kW 4 Pole T4C 3 Phase Cast Iron Electric Motor IE4 B3 ...
£8,616.34 (Inc. VAT at 20%)
£7,180.28 (Exc. VAT)Extended Product Description for TecMotors 200kW 4 Pole T4C Cast Iron Electric Motor
The TecMotors 200kW 4 Pole T4C Cast Iron Electric Motor, Three Phase, B3 Foot Mounted is engineered to deliver exceptional performance, reliability, and efficiency across a spectrum of industrial applications. Designed with robust materials, this motor sets the benchmark for energy savings and operational excellence.
Exceptional Energy Efficiency
With a powerful 200kW output and an operational speed of 1500 RPM, this motor is perfectly suited for demanding tasks in manufacturing, material handling, HVAC systems, and more. Its IE4 Super Premium Efficiency rating places it at the forefront of energy efficient technology, ensuring substantial reductions in power consumption and long term lowering of energy costs. Businesses can benefit from this efficiency while reducing their environmental footprint.
Durable and Reliable Design
Built to last, the motor's heavy duty cast iron construction offers unparalleled durability, making it ideal for rigorous industrial use and harsh environmental conditions. Its TEFC (Totally Enclosed, Fan Cooled) design ensures complete protection against external contaminants like dirt, dust, and moisture, ensuring reliable operation in both indoor and outdoor environments. The IP55 rating further enhances its resilience, making it impervious to water jets and dust ingress.
Advanced Safety and Performance Features
The motor is equipped with PTC thermistors, which act as thermal safety devices to prevent overheating, safeguarding it during prolonged operations and boosting its longevity. Furthermore, the inclusion of premium NSK bearings ensures smooth operation, reduced maintenance, and quieter performance over extended periods.
Standards Compliance and Versatility
Adhering to IEC 60034 standards, this motor meets global quality and reliability benchmarks, ensuring compatibility and compliance for use in worldwide industrial systems. Its insulation class F rating allows it to function seamlessly even in high temperature environments, proving its capability in demanding settings.
Flexible Installation
The B3 foot mounted design coupled with a multimount frame facilitates effortless installation, whether integrating into new systems or retrofitting existing ones. With a frame size of 315L2-4 and a shaft diameter of 80mm, it is compatible with a diverse range of industrial equipment and setups.
Key Applications
- Manufacturing Industry:Powers conveyor belts, production lines, and automated systems.
- Material Handling Solutions:Suitable for heavy machinery like cranes, hoists, and lifts.
- HVAC Systems in Industrial Plants:Ensures energy efficient operation of ventilation and cooling setups.
- Pumping and Fluid Systems:Capable of running high-capacity pumps and compressors.
- Outdoor Applications:Performs reliably in rugged outdoor environments exposed to dust, moisture, and temperature changes.
The TecMotors 200kW 4 Pole T4C Cast Iron Electric Motor combines technical excellence, robust design, and innovative energy saving attributes. Whether you need reliable equipment for industrial facilities, robust machinery for outdoor purposes, or energy-conscious solutions, this motor is your ideal choice for optimum performance and sustainability.
Specs Sheet - TecMotors 200kW 4 Pole T4C Cast Iron Electric Motor
Product Name:
TecMotors 200kW 4 Pole T4C Cast Iron Electric Motor
Specifications Overview:
- Output Power:200kW
- Speed:1500 RPM
- Mounting Type:B3 Foot Mounted
- Efficiency Class:IE4 Super Premium Efficiency
- Frame Size:315L2-4
- Shaft Diameter:80mm
- Voltage/Frequency:Three Phase, 50/60 Hz
- Construction Material:Heavy duty cast iron
- Insulation Class:F
Key Features:
- Design:TEFC (Totally Enclosed, Fan Cooled) for optimal protection against contaminants such as dirt, dust, and moisture.
- Protection Rating:IP55, ensuring excellent resistance to water jets and dust ingress for enhanced use in rigorous environments.
- Thermal Protection:PTC thermistors included as standard to protect against overheating and extend the motor's lifespan.
- Bearings:Equipped with durable NSK bearings for smooth and efficient operation with minimal wear.
- Standards Compliance:Built to IEC 60034 standards for international reliability and benchmarked quality.
- Installation Flexibility:Multimount frame makes installation adaptable and straightforward.
Applications:
- Manufacturing and production lines
- Material handling, including conveyors, cranes, and lifts
- Industrial HVAC systems for cooling and ventilation
- High-capacity pumping and fluid transfer systems
- Outdoor applications demanding robustness and reliability
Benefits:
- Significant reduction in energy consumption due to IE4-rated efficiency, leading to lower operational costs.
- Strong, heavy duty build ensures excellent durability in challenging industrial environments.
- Reliable performance with minimal maintenance, reducing downtime.
- Easy integration into existing or new industrial systems thanks to versatile installation options.
The TecMotors 200kW 4 Pole T4C Cast Iron Electric Motor is purpose-built for efficiency, durability, and performance. Whether it's for industrial machinery, outdoor use, or energy efficient systems, this motor is the go-to solution for long term productivity and cost savings.
Frequently Asked Questions (FAQs) - TecMotors 200kW 4 Pole T4C Cast Iron Electric Motor
1. What makes the IE4 Super Premium Efficiency rating important for this motor?
The IE4 rating signifies top-tier energy efficiency, making this motor a cost-effective choice. It significantly reduces energy consumption and operating costs while supporting environmental sustainability through lower energy waste.
2. How simple is it to install the motor in existing systems?
The motor's B3 foot mounted design and multimount frame ensure a smooth installation process. Whether you're retrofitting an older system or integrating it into new equipment, the design allows for versatile and straightforward alignment and set up.
3. What maintenance does the motor require to maintain optimal performance?
To keep the motor running efficiently, periodic maintenance is key. This includes cleaning off dust, ensuring proper lubrication of the NSK bearings, and checking the operation of the PTC thermistors. Regular inspections aligned with manufacturer recommendations will enhance performance and durability.
4. Is this motor suited for demanding industrial and outdoor environments?
Yes, the motor's heavy duty cast iron construction, TEFC (Totally Enclosed, Fan Cooled) design, and IP55 rating make it highly resilient to dust, dirt, and moisture. These features ensure reliable performance in industrial facilities and challenging outdoor applications.
5. What should do if the motor shows signs of malfunction?
If issues arise, inspect the motor for overheating, loose connections, or visible damage. The built-in PTC thermistors help mitigate the risk of overheating by cutting off the motor when necessary. For persistent problems, consult the detailed user manual or contact TecMotors' expert support team for specialized assistance.
