TecMotors 4kW 4 Pole 3 Phase Electric Motor IE3 B34 Foot and Face Mounting Frame Size 112

Introducing the TEC 4.043TECAB34-IE3 4kW 4 pole, three phase B34 foot and face mounted electric motor, designed to meet the rigorous demands of modern industries. Boasting IE3 efficiency with PTC thermistors fitted, this motor is a combination of performance, reliability, and energy efficiency. Crafted with meticulous precision, its aluminium multi-mount construction in an IEC frame size 112 makes it a versatile choice for a myriad of applications.

Extended Product Description:

High Efficiency Operation: The motor is engineered to deliver exceptional performance with an output power of 4kW, coupled with an IE3 efficiency rating. This ensures that it operates at the highest level of energy efficiency, significantly reducing operational costs while minimizing environmental impact.

Robust Construction: Built from high grade aluminium, the motor's construction guarantees outstanding durability and corrosion resistance, making it suitable for use in challenging environments. Its lightweight nature, owing to the aluminium construction, also facilitates easier installation and handling.

Versatile Mounting Options: Featuring B34 mounting, this motor offers the flexibility of both foot and face installation. This dual mounting capability allows for a more adaptable integration into various systems, making it ideal for applications that require specific mounting arrangements.

Advanced Temperature Monitoring:Equipped with PTC thermistors, this motor provides superior protection against thermal overload. The thermistors actively monitor the motor's temperature, ensuring it operates within safe limits, thus greatly extending its lifespan and maintaining consistent performance.

Optimised Design:With a frame size of 112, the motor is designed to fit seamlessly into a wide range of industrial applications. Its compact size, combined with the multi-mount options, ensure that it can be easily incorporated into limited spaces without compromising on power or efficiency.

Superior Insulation and Protection:The motor boasts an insulation class F, providing enhanced protection against heat and electrical overload. Its IP55 rating further ensures it is safeguarded against dust ingress and water jets from any direction, making it highly resilient in moist or dusty environments.

Applications:

This motor is perfectly suited for a variety of industrial applications, including but not limited to conveyor systems, pumps, fans, compressors, and machinery that require precise and efficient motor operation. Its robust design and high efficiency make it a reliable choice for continuous operation in demanding settings. In conclusion, the 4.043TECAB34-IE3 represents a significant leap forward in motor technology. It combines superior efficiency, advanced thermal protection, versatile mounting options, and durable construction into one compact, powerful package. Whether you are upgrading existing systems or designing new installations, this motor promises to deliver unparalleled performance and reliability, setting new standards in industrial operations.

Specifications Sheet for TecMotors 4kW 4 Pole Electric Motor, Three Phase, B34 Foot and Face Mounted (IE3 Efficiency)

General Information:

Product Name:4kW 4 Pole Three Phase Foot and Face Mounted Electric Motor

Model:4.043TECAB34-IE3

Output Power: 4kW

Pole Number: 4 Pole

Mounting Configuration: B34 (Foot and Face Mounted)

Construction Material:Aluminium

Frame Size:112

Phase:Three Phase

Insulation Class:F

Efficiency Class: IE3

Technical Features:

Rated Voltage: Compatible with standard three phase power supply voltages

Frequency: Designed to operate at standard industry frequencies of 50/60 Hz

Enclosure Type: Totally Enclosed Fan Cooled (TEFC)

Protection Rating: IP55

Cooling Method:

Fan Cooling Temperature Monitoring: PTC Thermistors fitted for advanced thermal protection

Performance Characteristics:

High Efficiency:Meets IE3 efficiency standards, ensuring lower energy consumption and operational costs.

Robust Construction:Aluminium construction provides a lightweight yet durable motor capable of withstanding harsh industrial environments.

Thermal Protection: Equipped with PTC thermistors to monitor and protect the motor from thermal overload.

Environmental and Compliance:

Environmental Protection:IP55 rated for protection against dust ingress and water jets, suitable for a wide range of environmental conditions.

Safety and Standards: Manufactured in compliance with IEC standards, ensuring high quality and safety.

Installation and Usage:

Flexible Mounting:B34 mounting allows for both foot and face installations, offering versatility in application.

Application Range:Ideal for industrial applications such as pumps, fans, conveyors, and machinery requiring precise control and efficient operation.

Additional Information:

Warranty:Comes with a manufacturer's warranty (specific terms and duration may vary).

Support and Service:Dedicated technical support and after sales service available.

Summary:

The 4kW 4 Pole Three Phase B34 Foot and Face Mounted Motor is a high efficiency, versatile solution designed for a multitude of industrial applications. It combines IE3 efficiency, aluminium construction, and PTC thermistor-based thermal protection into a compact, powerful package. With its dual foot and flange mounting capability, it offers flexibility in installation and is engineered to provide reliable, efficient performance in demanding environmental conditions.

Frequently Asked Questions for the 4kW 4 Pole Three Phase Foot and Face Mounted Motor (IE3 Efficiency)

1. What environments is this motor suitable for?

The motor's IP55 rating ensures it is protected against dust ingress and water jets from any direction, making it suitable for various environments including industrial settings, outdoor applications, and areas where moisture and dust are present. However, it should not be submerged or exposed to continuous, high-pressure water jets directly.

2. Can this motor operate on both 50Hz and 60Hz frequencies?

Yes, this motor is designed to operate efficiently at standard industry frequencies of 50/60 Hz, making it versatile for use in different global regions and applications. However, it's important to verify the voltage compatibility and performance characteristics at the intended frequency of operation.

3. What does the IE3 efficiency class mean for my operational costs?

The IE3 efficiency class indicates that this motor operates at a high level of efficiency, which translates into lower energy consumption for the same level of performance compared to motors with lower efficiency ratings. This results in significant savings on electricity costs over the lifespan of the motor, as well as reduced environmental impact.

4. How do PTC thermistors protect the motor?

PTC thermistors are temperature-sensitive components fitted within the motor that monitor its thermal condition. If the temperature inside the motor exceeds a predefined limit, the PTC thermistors trigger protective measures such as shutting down the motor or alerting the control system, thus preventing thermal damage and extending the motor's lifespan.

5. Can I use this motor for both foot and face mounting applications?

Yes, this motor features B34 mounting, which means it is designed for both foot and face mounting applications. This provides flexibility for various installation requirements and allows the motor to be integrated into a wide range of machinery and equipment setups seamlessly.
