TecMotors 75kW 2 Pole T4C Cast Iron Electric Motor, Three Phase, B3 Foot Mounted, Frame Size 280S-2, IE4 Efficiency

SKU: 75.023TECCB3-IE4

£3,366.59 (Inc. VAT at 20%)

£2,805.49 (Exc. VAT)

The TEC IE4, premium efficiency 75kW, 2 pole heavy duty cast iron electric motor offers versatile design for ease of installation, high efficiency for inverter use and high performance. This motor is IE4 rated meaning it's in a "Super Premium Efficiency" class for electric motors, one of the highest efficiency levels available for electric motors. It's IP55 rated, with a multimount frame and PTC thermistors fitted as standard. TEFC (Totally Enclosed, Fan Cooled), this motor is enclosed to prevent the ingress of contaminants, making it ideal for use in environments where exposure to dust, dirt, and moisture is a concern, such as industrial facilities, outdoor applications, and manufacturing plants. Fitted with NSK bearings. Conforms to IEC 60034 standards.

  • 75kW output power
  • 3000 RPM
  • B3 foot mounting
  • Heavy duty, cast iron construction
  • Frame size 280S-2
  • Three phase
  • 50/60Hz
  • Insulation class F
  • IE4 Super Premium Efficiency rating
  • Shaft diameter 65mm

Extended Product Description for TecMotors 75kW 2 Pole T4C Cast Iron Electric Motor

Experience the pinnacle of industrial motor engineering with the TecMotors 75kW 2 Pole T4C Cast Iron Electric Motor, Three Phase, B3 Foot Mounted. Tailored for high-demand usage, this motor delivers formidable performance, long-lasting durability, and unmatched efficiency, making it a staple for industrial, manufacturing, and outdoor operations. Built with precision and robust materials, it stands out as a reliable solution for powering heavy-duty applications.

Exceptional Energy Efficiency

This motor boasts a 75kW output power combined with a rapid 3000 RPM speed, ensuring seamless operation in demanding tasks that require consistency and precision. With its IE4 Super Premium Efficiency rating, the motor represents the forefront of energy-efficient technology, significantly reducing energy consumption while maintaining superior performance. This high-efficiency design not only supports sustainability practices but also cuts operational costs, offering an invaluable advantage for cost-focused enterprises.

Durable and Reliable Design

Designed for strength and longevity, the motor features a heavy-duty cast iron construction that ensures exceptional stability even under challenging conditions. Its TEFC (Totally Enclosed, Fan Cooled) design keeps internal components safe from external contaminants like dust, dirt, and water, making it suitable for harsh environments and outdoor applications. The motor's IP55 protection rating further guarantees resistance to moisture and particles, allowing it to function reliably in both controlled industrial setups and challenging outdoor locations.

Advanced Safety and Performance Features

Safety and reliability are at the core of this motor's innovative design. The inclusion of PTC thermistors provides superior thermal management, protecting the motor from overheating. Its NSK bearings, known for their low friction and high durability, contribute to reduced wear and extend the service life, minimizing maintenance requirements. Meanwhile, compliance with IEC 60034 standards solidifies its reputation as a globally recognized and trusted device adhering to stringent safety and performance regulations.

Flexible Installation

The motor is equipped with B3 foot mounting for straightforward installation in various setups, ensuring flexibility and adaptability. Its multimount frame expands installation options, enabling seamless integration into complex systems. With a 65mm shaft diameter, it easily pairs with a wide range of equipment, enhancing its compatibility and operational scope. Its insulation class F adds a layer of resilience, protecting it from heat-related damage and enabling it to endure temperatures up to 155°C.

Key Features

  • Output Power: Robust 75kW
  • Speed: Operates at an impressive 3000 RPM
  • Efficiency: IE4 Super Premium Efficiency for cost-effective energy use
  • Build Quality: Heavy-duty cast iron construction for extended durability
  • Design: Enclosed TEFC design shields from contaminants
  • Protection Rating: IP55-rated to resist dust and water
  • Thermal Safety: Includes PTC thermistors for effective temperature management
  • Bearings: High-quality NSK bearings for low maintenance and longevity
  • Standards Compliance: Meets global IEC 60034 quality and safety benchmarks
  • Mounting Options: B3 foot mounted with a multimount frame for versatile installation
  • Shaft Size: 65mm diameter for wide equipment compatibility
  • Thermal Rating: Insulation class F ensures reliable performance in high-heat applications

Primary Applications

  • Industrial Use: Perfect for powering equipment in manufacturing plants and assembly lines
  • Outdoor Applications: Designed to withstand tough environments and weather conditions
  • Material Handling Systems: Reliable for conveyors, hoists, and other automated operations
  • Pumps and Compressors: Ensures precise performance for fluid and air handling systems
  • HVAC Systems: Consistent energy-efficient operation for large-scale ventilation and cooling needs

Combining efficiency, durability, and advanced engineering, the TecMotors 75kW 2 Pole T4C Cast Iron Electric Motor is the ultimate choice for businesses striving for high performance and low operational costs. Designed to meet the toughest industrial standards, this motor delivers reliable, cost-effective service across various demanding applications. Choose TecMotors to power your operations with confidence and efficiency.

Specs Sheet - TecMotors 75kW 2 Pole T4C Cast Iron Electric Motor

Product Information:

Product Name: TecMotors 75kW 2 Pole T4C Cast Iron Electric Motor

Mounting Type: B3 Foot Mounted

Frame Size: 280S-2

SKU: 75.023TECCB3-IE4

Efficiency Class: IE4 Super Premium Efficiency

Technical Specifications:

  • Output Power: 75kW
  • Speed: 3000 RPM
  • Voltage: Three Phase (50/60Hz)
  • Shaft Diameter: 65mm
  • Insulation Class: F (resistant to temperatures up to 155°C)
  • Protection Class: IP55 (dust and water resistant)

Construction Features:

  • Material: Heavy-duty cast iron
  • Design: TEFC (Totally Enclosed, Fan Cooled) for contaminant protection
  • Frame Design: Multimount frame for versatile installation
  • Bearings: Premium NSK bearings for reduced friction and extended lifespan

Thermal and Safety Features:

  • Overheat Protection: PTC thermistors fitted as standard
  • Standards Compliance: Conforms to IEC 60034 standards for electric motors

Applications and Suitability:

  • Industrial and manufacturing machinery
  • Outdoor and harsh environments
  • Material handling systems
  • Pumps, compressors, and HVAC units

Key Benefits:

  • Energy Savings: Achieves significant reductions in operational costs with IE4 efficiency.
  • Durable Build: Heavy-duty construction ensures reliable performance in tough conditions.
  • Low Maintenance: NSK bearings and advanced thermal management systems reduce upkeep needs.
  • Flexible Installation: The B3 mounting and multimount frame provide an adaptable set up for various equipment and operations.

Select the TecMotors 75kW 2 Pole Electric Motor to enjoy robust performance, energy efficiency, and long-lasting durability across a wide spectrum of demanding applications.

Frequently Asked Questions (FAQs) - TecMotors 75kW 2 Pole T4C Cast Iron Electric Motor

1. What are the energy-saving benefits of the IE4 Super Premium Efficiency rating?

The IE4 rating is one of the highest efficiency standards for electric motors. It reduces energy consumption, cutting operational costs and promoting environmental sustainability. This efficiency is especially valuable in energy-intensive industries.

2. What is the process for installing the motor with the B3 foot mounting?

The motor's B3 foot mounting design makes installation straightforward. It securely attaches to a flat surface, and the multimount frame provides flexibility for adapting to specific setups, ensuring compatibility with a wide range of industrial equipment.

3. How much maintenance does this motor require?

The motor is designed for low maintenance, with robust cast iron construction and durable NSK bearings. Routine checks for bearing wear, proper lubrication, and cleaning of external surfaces will help sustain performance. Additionally, ensure proper airflow around the TEFC design to increase lifespan.

4. Is this motor suitable for outdoor or harsh industrial environments?

Yes, this motor is ideal for challenging conditions. Its heavy-duty cast iron frame, IP55 rating, and TEFC design protect against dust, dirt, and moisture, ensuring reliable operation in both indoor and outdoor environments.

5. What should I do if the motor overheats or stops working?

The motor is equipped with PTC thermistors that monitor and prevent overheating. If the motor shuts down, allow it to cool and check for potential blockages or overloading. For persistent issues, consult the user manual or reach out to TecMotors support for professional troubleshooting.
