TecMotors 90kW 4 Pole T4C 3 Phase Cast Iron Electric Motor IE4 B35 Foot & Flange Mounted, Frame Size 280M-4
£4,653.08 (Inc. VAT at 20%)
£3,877.57 (Exc. VAT)The TEC 90.043TECCB35-IE4 is 90kW, 4 pole, three phase, IE4 premium efficiency electric motor with B35 foot and flange mounting. Its frame and terminal box are made from cast iron, with a sheet steel fan cover and cast iron flanges and shields.
The motor is rated IP55, providing protection against dust and water jets. It has Class F insulation and IC411 cooling, with PTC (positive temperature coefficient) thermistors. Fitted with NSK bearings.
This T4C motor conforms to IEC 60034 standards and has an S1 continuous duty rating. The motor's IE4 rating means it's in a "Super Premium Efficiency" class for electric motors, one of the highest efficiency levels available.
This heavy duty, TEC cast iron motor is suitable for a range of industrial applications, including pumps, air compressors, fans, conveyors, material handling equipment and power transmission systems. It can also be used in wastewater treatment, agriculture, mining and other industrial environments.
TEC also supplies gearboxes and geared motors for applications requiring torque control and power transmission. These can be used alongside electric motors to meet different drive and mechanical transmission requirements.
- 90kW output power
- 4 pole
- Three phase
- 1485 RPM
- B35 foot and flange mounting
- IE4 Super Premium Efficiency rating
- Heavy duty, cast iron construction
- Frame size 280M-4
- 50/60Hz
- Insulation class F
- S1 continuous duty
- IP55 protection
- Shaft diameter 75mm
TecMotors 90kW 4 Pole T4C 3 Phase Cast Iron Electric Motor IE4 B35 Foot & Flange Mounted, Frame Size 280M-4 is backordered and will ship as soon as it is back in stock.
TecMotors 90kW 4 Pole T4C 3 Phase Cast Iron Electric Motor IE4 B35 ...
£4,653.08 (Inc. VAT at 20%)
£3,877.57 (Exc. VAT)Extended Product Description for TecMotors 90kW 4 Pole T4C Cast Iron Electric Motor
Experience unmatched power and durability with the TecMotors 90kW 4 Pole T4C Cast Iron Electric Motor. Designed to meet the highest industry standards, this advanced motor combines remarkable energy efficiency with exceptional performance and reliability. Perfect for demanding industrial and outdoor applications, it is a versatile and durable solution for a wide range of operational needs.
Exceptional Energy Efficiency
This motor carries an IE4 Super Premium Efficiency rating, placing it among the most energy efficient choices on the market. The ultra-efficient design reduces power consumption and operational costs, helping businesses achieve both economic and environmental sustainability.
Robust Construction for Demanding Applications
Crafted from heavy duty cast iron, this motor is built to endure harsh conditions while delivering consistent performance. Its B35 foot and flange mounting system offers effortless installation and compatibility with various machinery and systems. The multimount frame further enhances its adaptability, making it a go-to choice for diverse applications.
Superior Protection Against External Factors
- TEFC (Totally Enclosed, Fan Cooled) Design:Protects the motor from contaminants like dirt, dust, and moisture, ensuring secure operation even in tough environments.
- IP55 Rating:Designed to resist dust ingress and exposure to water sprays, providing lasting reliability in challenging settings.
- PTC Thermistors:Add an advanced layer of thermal protection by monitoring heat levels and preventing overheating.
High quality Components for Longevity
With its premium NSK bearings, the motor ensures reduced friction, smooth operation, and extended service life. These bearings also lower maintenance needs, allowing businesses to focus on productivity without interruption. Fully compliant with IEC 60034 standards, it guarantees superior quality and safety for peace of mind.
Key Specifications
- Output Power:90kW
- Rotational Speed:1500 RPM
- Mounting Type:B35 (foot & flange mounted for versatility)
- Frame Size:280M-4
- Shaft Diameter:75mm
- Frequency:50/60Hz
- Insulation Class:F (withstands temperatures up to 155°C)
Designed for Real-World Applications
This electric motor excels in heavy duty environments such as industrial plants, agricultural settings, and construction sites. It's ideal for operating machinery like pumps, fans, compressors, and conveyors. Whether used indoors or outdoors, its rugged design and high efficiency make it an essential piece of equipment for operations that demand reliability and performance.
Key Benefits
- Eco-Friendly Operation:The IE4 efficiency reduces carbon emissions, promoting sustainable practices.
- Durable Performance:Made from heavy duty cast iron and protected by an IP55 rated TEFC design.
- Flexibility and Compatibility:B35 foot and flange mounting ensures easy integration with various systems.
- Minimal Downtime:Advanced components like NSK bearings and PTC thermistors lower maintenance needs and prevent overheating.
- cost effective:energy efficient features lead to substantial long term savings.
The TecMotors 90kW 4 Pole T4C Cast Iron Electric Motor is the ultimate combination of efficiency, durability, and innovation. Designed to endure and outperform, it is the perfect addition to any industrial set up, ensuring high performance and low operating costs. Unlock the potential of long term productivity and reliability with this cutting edge electric motor.
Specs Sheet - TecMotors 90kW 4 Pole T4C Cast Iron Electric Motor
Product Information:
Product Name:TecMotors 90kW 4 Pole T4C Cast Iron Electric Motor
Mounting Type:B35 Foot and Flange Mounted
Frame Size:280M-4
SKU:90.043TECCB35-IE4
Efficiency Class:IE4 Super Premium Efficiency
Performance Details:
- Output Power:90kW
- Rotational Speed:1500 RPM
- Frequency:50/60Hz
- Insulation Class:F (capable of withstanding temperatures up to 155°C)
Mechanical Features:
- Construction Material:Heavy duty cast iron
- Mounting Style:Multimount frame with foot and flange mounting options
- Shaft Diameter:75mm
Protection & Durability:
- Cooling System:TEFC (Totally Enclosed, Fan Cooled), shielding the motor from contaminants like dirt, dust, and moisture
- Ingress Protection:IP55, ensuring defence against dust and protected against water spray
- Thermal Protection:Equipped with PTC thermistors for advanced heat monitoring and overheating prevention
Bearings:
- Type:Premium NSK Bearings for enhanced performance, reduced maintenance, and longevity
Compliance:
- Standards:Conforms to IEC 60034 standards for efficiency, reliability, and safety
Applications:
- Industrial Use:Ideal for operating pumps, fans, compressors, and conveyors in demanding environments
- Outdoor Engineering:Suitable for areas exposed to dust, moisture, and rugged conditions
- Industry Verticals:Manufacturing, construction, agriculture, and processing industries
Key Benefits:
- Energy Efficiency: The IE4 Super Premium Efficiency rating helps lower energy costs while maintaining peak performance.
- Sturdy Construction: Heavy duty cast iron build ensures reliability in tough conditions.
- Versatile Mounting: B35 foot and flange mounting allows flexibility in installation and system compatibility.
- Protected Operation: TEFC enclosure and IP55 rating defend against contaminants and environmental challenges.
- Minimal Maintenance: High quality NSK bearings and thermal protection extend operational life with reduced service needs.
The TecMotors 90kW 4 Pole T4C Cast Iron Electric Motor combines robust engineering, exceptional efficiency, and versatile functionality, making it the perfect choice for industries demanding high performance and durability in harsh conditions.
Frequently Asked Questions (FAQs) - TecMotors 90kW 4 Pole T4C Cast Iron Electric Motor
1. What makes the IE4 Super Premium Efficiency rating beneficial for this motor?
The IE4 rating reflects one of the highest levels of energy efficiency available for electric motors. This efficiency reduces energy consumption and lowers operational costs, making it both environmentally friendly and cost effective in the long term.
2. How is the motor installed, and does the B35 mounting offer flexibility?
The motor features a B35 foot and flange mounting system, providing versatility for installation. This design supports both foot and flange mounting options, making the motor compatible with various setups and machinery types.
3. What are the maintenance requirements for this motor?
Maintenance is minimal due to its durable cast iron construction, premium NSK bearings, and TEFC (Totally Enclosed, Fan Cooled) design. Regular inspections for dust or debris build up, along with occasional lubrication of the bearings, are recommended to ensure smooth and prolonged operation.
4. Is the motor suitable for industrial and outdoor applications?
Yes, the motor's heavy duty cast iron construction, IP55 ingress protection, and TEFC design make it ideal for industrial and outdoor conditions. It's resistant to dirt, dust, and moisture, making it suitable for demanding environments such as manufacturing plants, agricultural setups, and construction sites.
5. What should I do if the motor overheats or has performance issues?
The motor is equipped with PTC thermistors that monitor temperature and prevent overheating by shutting down the motor if required. If performance issues persist, consult the user manual for troubleshooting tips or contact TecMotors' support team for expert assistance.
